Device Type |
Multifunction Printer |
Product Category |
Production |
Color or Mono |
Color |
Print Speed |
70-90 PPM |
Mono Output Speed (A4 pages per min) |
81 |
Color Output Speed (A4 pages per min) |
71 |
Print Resolution(dpi) |
3600 x 1200 |
Copy Resolution (dpi) |
600 x 600 |
First Time To Print Mono (secs) |
4.0 |
First Time To Print Color (secs) |
6.5 |
Warm Up Time (secs) |
390 |
Output Size |
A5 – SRA3+ |
Output Size Max |
SRA3 |
Sheet Size PPG Only |
< or = SRA3 |
Monthly Print Volume |
200K |
Average Monthly Volume (A4 pages per mth) |
32,500 |
Average Monthly Print Volume |
32,500 |
Duty Cycle |
750K |
Standard Paper Input Tray 1 (Sheets) |
500 |
Standard Paper Input Tray 2 (Sheets) |
1000 |
Standard Paper Input High Capacity Feeder |
4630 |
Maximum Paper Input (sheets) |
15,390 |
Paper Weight Trays (gsm) |
62-350 |
Paper Weight Multiple Bypass (gsm) |
62-350 |
Standard Memory (GB) |
10GB |
Hard Drive Standard |
1.5 TB |
Document Feeder (sheets) |
300 |
Weight (kg) |
319 (main unit only) |
Dimension W x D x H (mm) |
800 x 903 x 1076 |
Dimension Inclusions |
Dimensions don’t include Automatic Document Feeder (ADF) |
Power Requirements (V / Amp / Hz) |
240 / 20 |
Max Power Consumption (kW) |
4.8 |
Energy Star Typical Energy Consumption (kWh/week) |
17.9 |
Automatic Duplex Unit Paper Weight (gsm) |
350 |
Automatic Duplex Unit Max Sheet Size |
SRA3 |
Options Available PPG Only |
Production Options |
Stapling Unit Output |
4,200 |
Folding and Punching Unit Output |
FD-503 (1000) |
Multi GBC Punching Unit Output |
GP-501 |
Stacking Unit Output |
LS-506 (5000 sheets) |
Booklet Making Unit Output |
SD-506 (50 sheets) |
Perfect Binding Output |
PB-503 (300 sheets) |
Main Unit Input |
1500 |
Paper Feed Unit Input |
4630 |
Relay Unit Input |
RU-518 |
Scan Type |
Dual Side High Speed color scanner |
Scanning Speed Simplex Max (ipm) |
240 |
Scanning Speed Duplex Max (ipm) |
240 |
Interface |
Ethernet 10/100/1000 Base-T, IPv6, USB 2.0 |
Protocol |
TCP/IP |
Dual Scan |
Yes |
Scanning Size Max |
A3 |
Scan Resolution |
600 dpi / 400 dpi / 300 dpi / 200 dpi |
Output Format |
PDF, TIFF |
Main Functions |
TWAIN scan, Scan-to-HDD, Scan-to-FTP, Scan-to-SMB, Scan-to-E-mail, Scan formats TIFF (single and multi page), PDF |
Modem Type |
0 |
Transmission Speed |
0 |
Scanning Speed |
0 |
Number of Stored Destinations |
0 |
Number of One Touch Destinations |
0 |
Number of Group Destinations |
0 |
Operating System Support |
Windows 7/8.1/10/Server 2008/Sever 2008 R2/Server 2012/Server 2012 R2/Server 2016 |
Processor |
Intel Core i5 4570 2.9GHz |
Supported Protocols |
TCP/IP (LPR, RAW socket), IPX/SPX (NDS, Bindery), NetBEUI, IPP, Ether Talk |
Processor |
Intel Core i5 4570 2.9GHz |
Printer Language |
Adobe PostScript3 (PS3020), PDF direct print (PDF version 1.7), TIFF direct print (TIFF version 6 compliance), PPML (version 2.2), PCL-5c compatible, PCL XL (PCL6 version 3) compatible |
Printer Interface |
PDF directprint (PDF Ver.1.7) / TIFF (TIFF Ver.6) direct print/PPML (Ver 2.1) |
