Description
ThinkBook 16p G5 IRX
|
1.
SD card reader
|
6.
Headphone / microphone combo jack (3.5mm)
|
|
2.
2x USB-A (USB 5Gbps)
|
7.
HDMI®
|
|
3.
Kensington® Nano Security Slot™
|
8.
Power connector
|
|
4.
USB-A (USB 10Gbps), Always On
|
9.
Pogo pin connector*
|
|
5.
2x Thunderboltâ„¢ 4
|
Performance
Processor
Processor Family
14th Generation Intel® Core i5 / i7 / i9 Processor
Processor**
| Processor Name | Cores | Threads | Base Frequency | Max Frequency | Cache | Processor Graphics |
|---|---|---|---|---|---|---|
| Core i5-14500HX | 14 (6 P-core + 8 E-core) | 20 | P-core 2.6GHz / E-core 1.9GHz | P-core 4.9GHz / E-core 3.5GHz | 24MB | Intel® UHD Graphics |
| Core i7-14650HX | 16 (8 P-core + 8 E-core) | 24 | P-core 2.2GHz / E-core 1.6GHz | P-core 5.2GHz / E-core 3.7GHz | 30MB | Intel® UHD Graphics |
| Core i9-14900HX | 24 (8 P-core + 16 E-core) | 32 | P-core 2.2GHz / E-core 1.6GHz | P-core 5.8GHz / E-core 4.1GHz | 36MB | Intel® UHD Graphics |
Operating System
Operating System**
- Windows® 11 Pro
- Windows® 11 Home
- Windows® 11 Home Single Language
- No preload operating system
Graphics
Graphics**
| Graphics | Type | Memory | Boost Clock | TGP | Key Features |
|---|---|---|---|---|---|
| NVIDIA® GeForce RTX 4050 Laptop GPU | Discrete | 6GB GDDR6 | 2370 MHz | 95W | DLSS 3, Dynamic Boost 2.0, DirectX® 12 Ultimate |
| NVIDIA® GeForce RTX 4060 Laptop GPU | Discrete | 8GB GDDR6 | 2370 MHz | 115W | Advanced Optimus, DLSS 3, Dynamic Boost 2.0, DirectX® 12 Ultimate |
Monitor Support
Monitor Support
Supports up to 4 independent displays (native display and 3 external monitors via HDMI® and Thunderbolt™) • HDMI® supports up to 8K@60Hz • Thunderbolt™ supports up to 5K@60Hz
Chipset
Chipset
Intel® HM770 chipset
Memory
Max Memory[1]
Up to 32GB DDR5-5600 offering
Memory Slots
Two DDR5 SO-DIMM slots, dual-channel capable
Memory Type
DDR5-5600
Notes:
- 1. The max memory is based on the test results with current Lenovo® memory offerings.
Storage
Storage Support[1]
Up to two drives, 2x M.2 SSD • M.2 2280 SSD up to 2TB each
Storage Slot
Two M.2 2280 PCIe® 4.0 x4 slots
Storage Type**
| Disk Type | Interface | Offering |
|---|---|---|
| M.2 2242 SSD | PCIe® NVMe®, PCIe® 4.0 x4 | 1TB |
| M.2 2280 SSD | PCIe® NVMe®, PCIe® 4.0 x4 | 512GB / 1TB |
Notes:
- 1. The system supports dual SSD via two M.2 slots, but Lenovo® only offers one SSD configuration, another SSD slot for user self-extension. The max storage capacity is only technical readiness and may be different from current Lenovo® storage offerings.
Removable Storage
Card Reader
SD card reader
Multi-Media
Audio Chip
High Definition (HD) Audio, Realtek® ALC3306-CG codec
Speakers
Stereo speakers, 2W x2 woofers and 2W x2 tweeters, Dolby Atmos®, sound by harman/kardon
Microphone
Dual-microphone array with smart noise-cancelling
Camera
FHD 1080p + IR hybrid, with privacy shutter, fixed focus
Sensor
Sensors
Ambient light sensor (ALS)
Battery
Battery
Integrated Li-Polymer 80Wh battery, supports Rapid Charge Pro (charge up to 50% in 30min)
Max Battery Life[1]
MobileMark® 25: 6.2 hr
Notes:
- 1. All battery life claims are approximate maximum and based on results using the MobileMark® 2014, MobileMark® 2018, MobileMark® 25, MobileMark® 30, JEITA 2.0, JEITA 3.0, continuous 1080p video playback (with 150nits brightness and default volume level) or Google Power Load Test (PLT) battery-life benchmark tests. Actual battery life will vary depending on many factors such as product configuration and usage, software use, wireless functionality, power management settings, and screen brightness. The maximum capacity of the battery will decrease with time and use.
Power Adapter
Power Adapter**[1]
- 230W slim tip (3-pin) AC adapter, 100-240V, 50-60Hz
- 300W slim tip (3-pin) AC adapter, 100-240V, 50-60Hz
Notes:
- 1. AC adapter offerings depend on the country.
Special Features
Special Features***
- AI Chip: LA3
- Modern Standby
Design
Display
Display**[1]
| Size | Resolution | Touch | Type | Brightness | Surface | Aspect Ratio | Contrast Ratio | Color Gamut | Refresh Rate | Viewing Angle (L/R/U/D) | Key Features |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 16″ | 2.5K WQXGA (2560×1600) | None | IPS | 400nits | Anti-glare | 16:10 | 1200:1 | 100% sRGB | 60Hz | 89° / 89° / 89° / 89° | Smart sense panel, X-Rite® factory color calibration (average ∆E<1), Dolby Vision®, Eyesafe® |
| 16″ | 3.2K (3200×2000) | None | IPS | 430nits | Anti-glare | 16:10 | 1200:1 | 100% DCI-P3 | 165Hz | 89° / 89° / 85° / 85° | Advanced Optimus, smart sense panel, X-Rite® factory color calibration (average ∆E<1), Dolby Vision®, Eyesafe® |
Color Calibration
X-Rite® factory color calibration
Touchscreen
Non-touch
Notes:
- 1. IPS (in-plane switching) technology may refer to IPS, PLS, ADS, AHVA, AAS.
Input Device
Pen
No support
Keyboard
6-row, spill-resistant, multimedia Fn keys, numeric keypad, Copilot key
Keyboard Backlight
LED backlight
Touchpad
Buttonless glass surface multi-touch touchpad, supports Precision TouchPad (PTP), 80 x 135 mm (3.15 x 5.31 inches)
Mechanical
Dimensions (WxDxH)[1]
354.6 x 258.2 x 19.9 mm (13.96 x 10.17 x 0.78 inches)
Weight[2]
Starting at 2.2 kg (4.85 lbs)
Case Color
Storm grey, dual-tone design
Surface Treatment
Anodizing sandblasting
Case Material
Aluminium (top), aluminium (bottom)
Notes:
- 1. The system dimensions may vary depending on configurations.
- 2. The system weight is approximate and based on results in Lenovo® lab, which varies depending on the source of component, variance of the distribution of each component, and manufacturing process. It may not be the exact weight for each specific model.
Connectivity
Network
Ethernet[1]
No onboard Ethernet
WLAN + Bluetooth[2]
Wi-Fi® 6E, 802.11ax 2×2 Wi-Fi® + Bluetooth® 5.3, M.2 card
WWAN
No support
Notes:
- 1. Wake-on-LAN needs the power adapter plugged in.
- 2. Wi-Fi® 6E full features might be limited by country-level restrictions. 6GHz Wi-Fi® 6E operation is dependent on the support of the operating system, routers/APs/Gateways that support Wi-Fi® 6E, and the regional regulatory certifications & spectrum allocation.
Ports[1]Â Click here to see ports position
Standard Ports
- 2x USB-A (USB 5Gbps / USB 3.2 Gen 1)
- 1x USB-A (USB 10Gbps / USB 3.2 Gen 2), Always On
- 2x USB-C® (Thunderbolt™ 4 / USB4® 40Gbps), with USB PD 3.0 and DisplayPort™ 1.4
- 1x HDMI® 2.1, up to 8K/60Hz
- 1x Headphone / microphone combo jack (3.5mm)
- 1x SD card reader
- 1x Power connector
Optional Ports
1x Magic Bay (pogo pin connector)
Notes:
- 1. The transfer speed of the ports will vary and, depending on many factors, such as the processing speed of the host device, file attributes and other factors related to system configuration and your operating environment, will be slower than theoretical speed.
Docking
Docking
Various docking solutions supported via Thunderbolt™. For more compatible docking solutions, please visit Docking for ThinkBook® 16p G5 IRX
Security & Privacy
Security
Security Chip
Firmware TPM 2.0 integrated in chipset
Physical Locks
Kensington® Nano Security Slot, 2.5 x 6 mm
Fingerprint Reader
Touch style fingerprint reader integrated in power button, match-on-chip
BIOS Security
- Hard disk password
- Power-on password
- Supervisor password
- User password
- Self-healing BIOS
- More BIOS security features, please visit BIOS Simulator
Other Security
- Camera privacy shutter
- IR camera for Windows® Hello (facial recognition)
Service
Warranty
Base Warranty**
- 1-year courier or carry-in service
- 2-year (1-yr battery) courier or carry-in service
Accessories
Bundled Accessories
Bundled Accessories[1]
- Lenovo® Magic Bay Light
- None
Notes:
- 1. For more compatible accessory solutions, please visit Accessories for ThinkBook® 16p G5 IRX.
Operating Requirements
Operating Environment
Temperature[1]
- At altitudes up to 2438 m (8,000 ft) – Operating: 5°C to 35°C (41°F to 95°F) – Storage: 5°C to 43°C (41°F to 109°F)
- At altitudes above 2438 m (8,000 ft) – Maximum temperature when operating under the unpressurized condition: 31.3°C (88°F)
Relative Humidity
- Operating: 8% to 95% at wet-bulb temperature 23°C (73°F)
- Storage: 5% to 95% at wet-bulb temperature 27°C (81°F)
Altitude
Maximum altitude (without pressurization): 3048 m (10,000 ft)
Notes:
- 1. When you charge the battery, its temperature must be no lower than 10°C (50°F).
Environmental
Sustainability
Material[1]
50% recycled aluminum alloy on bottom cover 25% PCC recycled plastic used in the battery pack enclosure 50% PCC recycled plastic used in key caps 30% PCC recycled plastic used in speaker enclosure 90% recycled content in PIC cushion 90% recycled content in OBP bag 100% use of paper in screen film FSC certified content in carton box
Notes:
- 1. PCC: Post Consumer Content, recycled materials from customers.
Certifications
Green Certifications[1]
Green Certifications[2]
- ENERGY STAR® 8.0
- EPEATâ„¢ Gold Registered[3]
- ErP Lot 6/26
- RoHS compliant
- TCO Certified 9.0
Notes:
- 1. The items listed under the “Green Certifications” section may not only refer to certification but also registration or self-declaration. For ESG & regulatory compliance documents, please visit https://compliance.lenovo.com.
- 2. EPEAT™ registration and ENERGY STAR® certification are optional and only available on the models with preloaded OS. Please visit epeat.net and energystar.gov for more information.
- 3. EPEAT is registered where applicable, please visit epeat.net for registration status by country.
Other Certifications
Mil-Spec Test
MIL-STD-810H military test passed
Other Certifications
- Eyesafe® Certified 2.0
- TÜV Rheinland® Low Blue Light (Hardware Solution)
- Feature with ** means that only one option listed under the feature can be configured on selected models. Please refer to the model configuration for specific information.
- Feature with *** means that one or more options listed under the feature can be configured on selected models. Please refer to the model configuration for specific information.
- Lenovo reserves the right to change specifications or other product information without notice. Lenovo is not responsible for photographic or typographical errors. LENOVO PROVIDES THIS PUBLICATION “AS IS,” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING THE IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. Some jurisdictions do not allow disclaimer of express or implied warranties in certain transactions, therefore this disclaimer may not apply to you.
- The specifications on this page may not be available in all regions, and may be changed or updated without notice.
