PERFORMANCE
Processor
Intel® Core™ Ultra 7 258V, 8C (4P + 4LPE) / 8T, Max Turbo up
to 4.8GHz, 12MB
AI PC Category[1]
Copilot+ PC
NPU
Integrated Intel® AI Boost, up to 47 TOPS
Graphics
Integrated Intel® Arc™ Graphics 140V
Chipset
Intel® SoC Platform
Memory
32GB Soldered LPDDR5x-8533, MoP Memory
Memory Slots
Memory soldered to systemboard, no slots, dual-channel
Max Memory
32GB soldered memory, not upgradable
Storage
1TB SSD M.2 2242 PCIe® 4.0x4 NVMe® Opal 2.0
Storage Support[2]
One drive, up to 2TB M.2 2242 SSD
Storage Slot
One M.2 2242 PCIe® 4.0 x4 slot
Card Reader
None
Audio Chip
High Definition (HD) Audio, Cirrus Logic® CS42L43
Speakers
Stereo speakers, 2W x2, Dolby Atmos®
Camera
FHD 1080p + IR Discrete with E-shutter
Microphone
2x, Array
Battery
55Wh
Power Adapter
65W USB-C® Slim GaN (3-pin)
DESIGN
Display
14" WUXGA (1920x1200) OLED 400nits Anti-glare, 100% DCIP3, 60Hz, DisplayHDR™ True Black 500, Dolby Vision®
Touchscreen
None
Keyboard
Backlit, English (UK)
Touchpad
Buttonless glass surface multi-touch Haptic Touchpad,
supports Precision TouchPad (PTP), 80 x 130 mm (3.15 x 5.12
inches)
Case Color
Grey
Case Material
Aluminium (Top), Aluminium (Bottom)
Pen
Pen Not Supported
Dimensions (WxDxH)[3]
311.8 x 212.3 x 6.7 - 17.18 mm (12.28 x 8.36 x 0.26 - 0.68 inches)
Weight[4]
Starting at 1.21 kg (2.66 lbs)
SOFTWARE
Operating System
Windows® 11 Pro, English (US) / English (UK)
Bundled Software
Intel® Connectivity Performance Suite
CONNECTIVITY
Ethernet[5]
No Onboard Ethernet
WLAN + Bluetooth®[6]
Intel® Wi-Fi® 7 BE201, 802.11be 2x2 + BT5.4
WWAN
Non-WWAN
SIM Card
None
NFC
None
Standard Ports
2x USB-C® (Thunderbolt™ 4 / USB4® 40Gbps), with USB
PD 3.0 and DisplayPort™ 2.1
•
• 1x HDMI® 2.1, up to 4K/60Hz
• 1x Headphone / microphone combo jack (3.5mm)
Optional Ports (configured)
None
Docking
Various docking solutions supported via Thunderbolt™ / USBC®.
For more compatible docking solutions, please visit Docking
for ThinkPad® X9-14 Gen 1
SECURITY & PRIVACY
Smart Card Reader
None
Security Chip
Discrete TPM 2.0 Enabled
Fingerprint Reader
Touch Style, Match-on-Chip, Integrated in Power Button
Other Security
• Ultrasonic Human Presence Detection (WUXGA models)
• E-shutter
• IR camera for Windows® Hello (facial recognition)
MANAGEABILITY
System Management
Non-vPro®
SERVICE
Base Warranty
3-year, Courier or Carry-in
Included Upgrade
None
ACCESSORIES
Bundled Accessories[7]
None
CERTIFICATIONS
Green Certifications[8]
• ENERGY STAR® 8.0
• EPEAT™ Gold Registered
• ErP Lot 6/26
• RoHS compliant
• TCO Certified 10.0
Other Certifications
• Eyesafe® Certified 2.0
• Intel® Evo™ Platform
