Cabinet 12U 600X600

12U 600 x 600 - Wall Mount - Single Section Cabinet
Avalon Cabinets are feature-rich rack enclosures optimized for easy installation, managing cables,
integrating power distribution, and maximizing airflow. These racks are multi-functional rack enclosures
designed to meet current IT market trends and applications ranging from high density computing and
networking to broadcast and audio-video.
Dimensions
Type 19 inch standard
Size 12U
Width 600 mm
Height 600 mm
Depth 600 mm
Gross Weight 26 KG (Including the packaging)
Net Weight 24 KG
Cabinet Features
 19” mounting angles
 Front Glass Door with Lock (Tempered Glass)
 Doors can be mounted to be opening from either
side
 Lock on the front door with duplicate keys
 Removable side panels
 Extra cage nuts provided
 Earthing screws
 Cooling fan Optional with effective ventilation
Technical Specifications
 All steel construction
 Frame made of 1.2 mm thick SPCC
 Fixed shelves made of 1.2 mm thick SPCC (Optional)
 Mounting angles made of 2.0 mm thick steel
 Strong structure of individually fabricated components
 Manufactured using CNC machine
 Surface Finish: Matt Black Epoxy Powder Coated Paint (RAL 9005)
Cooling fan with effective ventilation (Optional)
 Cooling Fan: Lower noise, Less than 48db, Air flow 50-110 CBM/H
Ordering Information
Size Width Depth Part No.
12U 600 mm 600 mm AN-WM12U600X6

✅ Contact for Latest Price
